| PCB Design Service Information | |
| We are a PCB Design Service Bureau active for the past 20 years. The support of client's has enabled us to upgrade our service, gain experience & insight such that the layout is correct the first time. A cost effective service for product development efforts is being supported by details of our Design and Manual Routing Service. A rare aptitude and ability to educate and learn after formal education has been stopped are our real inherent strengths coupled with a desire to upgrade. Service, Quality, CAD Compatibility, Experience and a Short turn around time will be the essence of our participation with your Product Development Team. We Support and Partner with Clients to work as a Offsite Design Team and do provide them with a Dependable PCB Design Source. |
|
| Our Design Experience | |
| From 1981-85 designed PCB's with Ink and Tape, 84-85 migrated to CAD. | |
| Processed Multi-Layer PCB's with mixed components on both the sides. | |
| Experienced in High Speed Designs with Differential / Controlled Impedances | |
| Autorouter is used to evaluate the goodness of placement & density of routing. | |
| Manual routing & DFM is followed with post routing cleanup. | |
| We have autorouted multilayer PCB's only to complete the direct connections. | |
| Team Spirit, Aptitude and Ability to learn are our real strengths. | |
|
PCB's Designed |
|
| Data Acquisition System / PLC's. | CNC Control / Test & Measuring. |
| Power Supplies LINEAR / SMPS. | Image processing / Video Cards. |
| X-ray / Ultra Sound Imaging. | Lift Control Cards / DPM. |
| Printers/Typewriters/Keyboards. | Rugged Industrial PC xxx86. |
| Single Board PC / Interface cards. | SCSI / DSP Cards / PCI Cards. |
| EPBX Exchanges / Telephones. | Gerber to PCB Database. |
| PC based comm cards / Modems. | Pentium II with AGP Chipset |
| VME Graphics/CPU/19" M'boards. | AC-DC Drives / Softstart. |
| Differential / Controlled Impedance Design | Network Routers and Network PC |
| LAN Cards / T1E1 / T3E3 / Uplink | Hubs and Switches |
| High Speed Designs | More to Come ................ |
| CAD Tools | |
| PADS PowerPCB V 3.5 / PADS Perform / Cadstar for Windows Experience on Mentor Board Station and Mentor to PADS Perform interface. We can migrate to client specific Tools. | |
|
Clients |
|
| We support Clients, as if we are an In-house Team, they prefer to have a dependable source. References if required shall be provided on request. | |
| How we could Serve you better | |
| Technical Conditions | |
| Initial Inputs with complete Information of all parts is required. | |
| Layout Guidelines and or Specifications to be part of inputs. | |
| Adjustments could be made to make the flow of information ripple free. | |
| Preferences for information exchange for initial Inputs be provided to us. | |
| Power-PCB is our preferred Cad-Tool. | |
| We always offer a first on line Service to our Clients. | |
| We accept work and new Clients only when we can offer a first on line status. | |
| Delivery Schedule depends upon the Inputs and the complexness of the design. | |
| Post Design, priority service support for a period of 90 days is promised by us. | |
| Commercial Conditions | |
| A Purchase Order is necessary to support our design efforts. | |
| Payment on completion and delivery of job will be appreciated. | |
| Mode of Payment is by Wire Transfer, timely Instructions shall be provided. | |
| We prefer to quote on an hourly basis, an initial estimate will be provided by us. | |
| In case of time overrun due to changes in design, due compensation is desired. | |
| Time Overrun occurs due to changes in Schematics or incorrect initial information. | |
| Prices depend upon the complexity and the estimated time to complete the job. | |
| We also quote on a fixed Time and Price basis. | |
|
Deliverables |
|
| Design Files in binary and ASCII, in zipped form as backup. | |
| Gerber files with embedded Aperture in RS274-X format. | |
| CNC Drill Files in Excellon Format. | |
| Pick & Place files in a format supported by PADS Software. | |
| Layer Stack-up information with associated Gerber file names. | |
| Assembly Drawing both sides. | |
| PCB Fabrication Drawing. | |
| List of Un-connected Pins. | |
| Final Net-list. | |
| Back annotation file. | |
| Compiled Part-list based on the different Part types used. | |
| CAM file for generating Gerber Files. | |
|
Options |
|
| We offer On-Site Service to interact with your design efforts on a retainer basis. This option is only applicable for Offshore Design Contracts. | |
| Agreements | |
| Non-disclosure Agreement is always implied and acceptable, are open to suggestions. | |
| We invite you to experience our PCB Design Service | |
